Electronic Elastic Ribbon Splicing Sewing Machine

Electronic Elastic Ribbon Splicing Sewing Machine

Electronic elastic ribbon splicing sewing machine ST-8430FX-R ·Beautiful sewing and easy to adjust sewing functions . ·Stable sewing quality with Digital Tension. ·Extremely low noise and vibration for operator-friendly sewing. ·Overwhelmingly superior productivity with the fast cycle time. ·High energy saving . ·Easy maintenance. ·Clean sewing with semi-dry type. ·User-friendly Operation panel. ·Environment-conscious.

Model:ST-8430FX-R

Send Inquiry

PDF Download

Product Description

Electronic elastic ribbon splicing sewing machine ST-8430FX-R

Electronic Elastic Ribbon Splicing Sewing Machine

Introduction


·Beautiful sewing and easy to adjust sewing functions .

·Stable sewing quality with Digital Tension.

·Extremely low noise and vibration for operator-friendly sewing.

·Overwhelmingly superior productivity with the fast cycle time.

·High energy saving .

·Easy maintenance.

·Clean sewing with semi-dry type.

·User-friendly Operation panel.

·Environment-conscious.


Feartures

Direct drive


Specifications:ST-8430FX-R


ST-8430FX-L

ST-8430FX-R

ST-8430FX-BZ

Application

Belt loop

Elastic stitch

Pillow stitch

Stitch formation

Single needle lock stitch

Max.sewing speed

3,200sti/min

Sewing area (X-Y)

  Max.40*30mm

Stitch length

0.05-12.7mm

Feed mechanism

Y-θ intermittent feed mechanism(pulse-motor driven mechanism)

No.of stitches

Variable(Refer to"Program List" for details on the number of stitches for sewing patterns that are already preset.)

Max.No of stitches

5,000 stitches/pattern

Work clamp lifter

Pulse motor drive system

Work clamp height /Button clamp height

Max .17mm

Max .50mm

Rotary hook

Shuttle hook  (Double shuttle hook,optional)

Digital tension

Standard equipment

Thread wiper

Standard equipment

Thread trimmer

Standard equipment

Thread nipper

Standard equipment

Data storage method

Flash memory(Any sewing pattern can be added using SD card)

External data storage method

SD card

No.of cycle programs

30 cycle(50 programs for each cycle)

No. of stored data

89 sewing patterns are set already

Up to 512 patterns can be added .Total number of stitches of stored data which can be added is within 500,000

Motor

AC servo motor 550W (Direct drive)

Power supply

Single-phase 110V/220V/230V,3-phase 220V/380V/400V,400VA


Delivery and Service:

· The machines have enough stock and can delivery within 7days.

· One year guarntee in mechanism parts except the quick-wear parts, three years guarntee in electronic parts.
